304 316 317l Hairline Finish Stainless Steel Plate Sheets Brush 1.0mm 0.9mm
| Place of Origin | Guangzhou China |
|---|---|
| Brand Name | Z.S.B |
| Model Number | 300 Series,400 Series,200 Series, |
| Minimum Order Quantity | 1 TON |
| Price | Negotiable |
| Delivery Time | 5-14 work days |
| Payment Terms | L/C, T/T, Western Union, MoneyGram, D/P |
| Supply Ability | 500 tons per month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Application | Construction,Kitchenware,Decoration,chemical,Industry | Width | Or As Required |
|---|---|---|---|
| Type | Plate Sheet | Standard | ASTM,JIS,AISI,EN,GB |
| Length | Customer's Request,1000-6000mm Or Customer's Requirement | Grade | 300 Series,400 Series,200 Series,201/202/304 /304L/316/316L321/310s/410/420/430/440/439ect |
| Surface | BA,2B,BA/2B/NO.1/NO.3/NO.4/8K/HL/2D/1D,HL,2D | Thickness | 0.3mm 1mm 3mm |
| High Light | 317l Stainless Steel Plate Sheets,Hairline Stainless Steel Plate Sheets,Hairline Finish Stainless Steel Sheet |
||
Product Description
304 316 317l Brush 1.0mm Finish 0.9 Mm Hairline Cr 321 Stainless Steel Sheet 316l
Stainless steel features:
317L (00Cr19Ni13Mo3, UNS S31726) alloy is an austenitic stainless steel based on molybdenum. It has greater chemical resistance than conventional chromium-nickel austenitic stainless steels such as alloy 304. In addition, compared with conventional stainless steel, 317L alloy has higher ductility, stress corrosion resistance, compressive strength and high temperature resistance. It is a low carbon grade or L grade, which is resistant to sensitization during welding and heat treatment.
Compared with 316L, 317L steel has good seawater resistance and SCC resistance, and is used in chemical ships, chemical product Reactors and other chemical equipment that require high corrosion resistance.
SUS317L mechanical properties: YS (Mpa) ≥ 176, TS (Mpa) ≥ 480, EL (%) ≥ 40, Hv ≤ 200
SUS317L chemical composition: carbon (C) ≤ 0.030, manganese (Mn) ≤ 2.00, nickel (Ni) 11.0 ~ 15.0, silicon (Si) ≤ 1.00, phosphorus (P) ≤ 0.045, sulfur (S) ≤ 0.030, chromium (Cr )18.0～20.0, molybdenum (Mo)3.0～4.0.
A molybdenum-containing austenitic chromium-nickel steel with a slightly higher alloy content than the 316 grade.
Excellent corrosion resistance in harsh environments.
Higher creep, fracture stress and tensile strength than other stainless steels.
Intergranular precipitation of chromium carbide is reduced during welding and stress relief, and the possibility of corrosion failure due to intergranular corrosion is minimized due to the low carbon content.
Resistance to pitting and crevice corrosion makes 317L a successful life cycle cost product in a variety of highly corrosive environments.
Product of description
| item | value |
| Length | 1000-6000mm |
| Thickness | 0.15-100mm |
| Width | 600-2500mm |
| Brand Name | Z.S.B |
| Type | Plate |
| Application | Construction |
| Processing Service | Bending, Welding, Decoiling, Punching, Cutting |
| Steel Grade | 301L, S30815, 301, 304N, 310S, S32305, 410, 204C3, 316Ti, 316L, 441, 316, L4, 420J1, 321, 410S, 410L, 436L, 443, LH, L1, S32304, 314, 347, 430, 309S, 304, 439, 204C2, 425M, 409L, 420J2, 436, 445, 304L, 405, 370, S32101, 904L, 444, 301LN, 305, 429, 304J1, 317L |
performance
317L is a molybdenum-containing austenitic chromium-nickel steel similar to Type 316, except that the alloy content in 317L is slightly higher. It offers excellent corrosion resistance in special applications where minimal contamination is required. 317L was developed primarily to resist attack by sulfite compounds more effectively. However, its proven ability to resist corrosion has greatly expanded its usefulness and is now being used in many other industrial applications. The low carbon content of 317L provides resistance to intergranular corrosion in applications where large cross sections cannot be annealed after welding or where low temperature stress relief is required.
Product Show
FAQ
Q:May I have an inspection of your factory?
A:Sure, you're welcome any time.
Q:Can I personalize the product?
A:The minimum order quantity is more than 10 tons, we can meet your personalized requirements.
Q:How I believe you?
A:We consider honest as the life of our company, Besides, there is trade assurance from Alibaba, your order and money will be well guaranteed.
Q:What is your delivery time?
A:We are based on the quantity of products to determine the delivery time, you can consult us for the answer.
